Nwdiag problem with address label position on peer network

asked Jan 13, 2023 in Bug by Serge Wenger Work (15,620 points)

On the following diagram the address "dhcp" should be below Dev3

Your answer

Your name to display (optional):

Email me at this address if my answer is selected or commented on:

Privacy: Your email address will only be used for sending these notifications.

Anti-spam verification:

Please complete the anti-spam verification

[Antispam2 Feature: please please wait 1 or 2 minutes (this message will disappear) before pressing the button otherwise it will fail](--------)

To avoid this verification in future, please log in or register.

1 Answer

answered Jan 16, 2023 by The-Lu (64,760 points)
selected Jan 17, 2023 by Serge Wenger Work

Best answer

Hello S., and all,

FYI, it is fixed on ~v1.2023.1beta4 by:

https://github.com/plantuml/plantuml/commit/db9080e28feb9cb4fb0666581f30dd2068602260#diff-752aced00ccab8dc120c875b646774d661679db63869252786bbf512d53006a1

Thanks to PlantUML team,
Regards.

commented 3 days ago by The-Lu (64,760 points)

Hello PlantUML team,

It seems there is a little regression on this side...

On V1.2024.5beta1 the label seems to be missing...
See diagram above.

See new similar request here:
- https://github.com/plantuml/plantuml/issues/1752

A new correction will have to be made...
Thanks for your new work.

Regards,
Th.
