adding label stretches horizontal arrow between use cases

0 votes
asked Feb 29, 2020 in Bug by anonymous

1 Answer

0 votes
answered Feb 29, 2020 by plantuml (265,360 points)

It may be related to your graphviz version. Could you check it ?


commented Feb 29, 2020 by albert (3,180 points)
When using dot version 2.38 (dot - graphviz version 2.38.0 (20140413.2041))  I get the short line graph (the bottom image), with version 2.40 (dot - graphviz version 2.40.1 (20161225.0304)) I get the long line one (top image)
commented Mar 2, 2020 by Serge Wenger Work (14,580 points)

Good news: with graphviz version 2.42.2 installed (report 2.43.0!!!!), it is like 2.38

commented Mar 2, 2020 by albert (3,180 points)
Good to know that there is a newer graphviz version, did you compile from source or where did you find the executables?
commented Mar 3, 2020 by Serge Wenger Work (14,580 points)

My colleage do a test on his own linux at home with last Fedora. For our old linux, he compile it from sources.

For Fedora for example:
